Panasonic AJ-D400 - Manual (Page 115)

– 115 –
Item
BLACK
WHITE (V. SAW)
BLACK COMPE
WHTE COMPE
Variable
range
Remarks
VF
display
——
——
ON
OFF
ON
OFF
Auto black shading (digital) activated
Auto white shading (V. SAW) activated
Black compensation ON/OFF
White compensation ON/OFF
ENG
ENG
ENG
ENG
Setting Menu Screens
AUTO SHADING Screen
This page performs the auto shading settings. Align the arrow with the desired BLACK or WHITE item and press the UP or
DOWN button to execute the setting.
The underlined setting in the Variable range column indicates the preset mode.
DATA RESET Screen
This page resets the menu display item settings. Aligning the cursor (arrow) with the item and pressing the UP or DOWN
button resets the settings.
Item
DATA RESET
Variable
range
Remarks
VF
display
—— Sets the setting menu to the status
when shipped from the factory. ENG
Item
OPERATION
DRUM RUNNING
THREADING
VTR SYSCON
CAM SYSCON
Variable
range
Remarks
VF
display
——
——
——
——
——
Operating time with the power ON
Drum rotating time
Loading time
Software version display
Software version display
ENG
ENG
——
ENG
ENG
Menu screen display methods
USER menu: Setting the MENU switch to SET displays the USER menu.
ENG menu:
Holding down the SHIFT/ITEM and UP buttons simultaneously and setting the MENU switch to SET displays
the ENG menu.
|
Note
{
The flare compensation value (LEVEL 4/6) and shading compensation value (AUTO
SHADING) do not return to the default settings.
DIAGNOSTIC Screen
This page displays the unit’s operating conditions and software version.
- AUT SHAD I NG -
¢ B L ACK
WH I T E ( V . SAW )
B L ACK COMP E : ON
WH I T E COMPE : ON
O
- DA T A RESE T -
¢ MENU I N I T .
- D I AGNOS T I C -
OPERA T I ON : 0 0 0 0 0 ∑ 1 0 h
DRUM RUNN I NG : 0 0 0 0 0 ∑ 1 0 h
THREAD I NG : 0 0 0 0 0 ∑ 1 0
V TR SYSCON : V e r < 1 . 0 >
CAM SYSCON : V e r < 1 . 0 >
