– 112 –
E
: ON
. : OFF
Item
F2.8 ADJ
F16 ADJ
Variable
range
Remarks
VF
display
——
——
Voltage is output only when selected
by the cursor (arrow).
Voltage is output only when selected
by the cursor (arrow).
ENG
ENG
|
Note
{
When using a lens which allows the lens iris open or close end to be adjusted, set
either “F2.8 ADJ” or “F16 ADJ” to ON and repeatedly adjust the lens iris until it is
“F2.8” or “F16”, respectively. (Fujinon S18
q
6.7 BRM4/BERM4 lenses do not have
this adjustment function.)
MENU SELECT 1/3 Screen
This page performs the menu page display ON/OFF settings. The ON/OFF status for each item is indicated by displaying an
asterix (
E
) or period (.) in front of the item on the screen.
Item
MARKER
VF DISPLAY
CAMERA ID
SHUTTER
SPEED
SYNCHRO
SCAN
!LED
MAIN FUNCTION
BATT/TAPE
ALARM
Variable
range
Remarks
VF
display
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
MARKER item user menu display
ON/OFF
VF DISPLAY item user menu display
ON/OFF
CAMERA ID item user menu display
ON/OFF
SHUTTER SPEED item user menu
display ON/OFF
SYNCHRO SCAN item user menu
display ON/OFF
!LED item user menu display ON/OFF
MAIN FUNCTION item user menu
display ON/OFF
BATT/TAPE ALARM item user menu
display ON/OFF
ON:
This switches the display ON.
OFF:
This switches the display OFF.
ENG
ENG
ENG
ENG
ENG
ENG
ENG
ENG
The underlined setting in the Variable range column indicates the preset mode.
Menu screen display methods
USER menu: Setting the MENU switch to SET displays the USER menu.
ENG menu:
Holding down the SHIFT/ITEM and UP buttons simultaneously and setting the MENU switch to SET displays
the ENG menu.
E
: ON
. : OFF
Setting Menu Screens
LENS ADJ Screen
This page performs the lens adjustments. The ON/OFF status for each item is indicated by displaying an asterix (
E
) or period
(.) in front of the item on the screen.
- L ENS AD J
-
¢
E
F 2 . 8 AD J
. F 1 6 AD J
- MENU SE L ECT
1 / 3 -
¢
E
MARKER
E
V F D I SP L AY
E
CAMERA
I D
. SHUT TER SPEED
E
SYNCHRO SCAN
. ! L ED
E
MA I N FUNCT I ON
. BAT T / TAPE A L ARM
