Installation (continued)
Adjusting the feet
The four adjustable feet (p. 14) mounted at the bottom of the projector are level-adjustable (0 mm–15 mm) which
can be used when the mounting surface is uneven.
(Front) (Rear)
Projection scheme
All four combinations of Front, Rear, Ceiling or Floor mounting are available. Use the INSTALLATION menu to
choose the desired projection scheme. (p. 78)
Installation geometry
When planning the projector and screen geometry, refer to the figures below and the information on the next page
for reference. After the projector is roughly positioned, picture size and vertical picture positioning can be finely
adjusted with the powered zoom lens and lens shifting mechanism.
When attaching an optional ceiling mount bracket (ET-PKD100H)
z
254
580.5 - 700.5
H
H
SH
L
L
(10˝)
(22.9
˝ - 27.6
˝)
Side View (unit : mm/inch)
Screen
L
175
254
200
SW 314
120
66
(12.4
˝)
(4.7
˝)
(2.6
˝)
(6.9˝)
(10˝)
(7.9˝)
L1
Top View (unit : mm/inch)
Screen
L Projection distance
SH Height of the image
SW Image width
H
Vertical distance between the lens center level and
the bottom edge of the projected image
* For PT-D12000U: H = 0 to SH
For PT-DZ12000U: H = -0.1 × SH to 1.1 × SH
* However, if the ET-D75LE5 has been installed,
the value will be fixed at H=SH/2 for both the
PT-D12000U and PT-DZ12000U. If the ET-D75LE6
has been installed, the values will be H = 0.1 × SH
to 0.9 × SH for the PT-D12000U, and H = 0 to SH
for the PT-DZ12000U.
Lens
Lens Protrusion L1
(Approx.)
ET-D75LE1 62.5 (2.5˝)
ET-D75LE2 47 (1.9˝)
ET-D75LE3 50.5 (2˝)
ET-D75LE4 74.4 (2.9˝)
ET-D75LE5 150.5 (5.9˝)
ET-D75LE6 160 (6.3˝)
ET-D75LE8 202.5 (8˝)
