Recording
Locking the time code to the external time
code
The unit’s time code generator can be locked to an
external time code generator.
Example of connections used for locking to an external time code
Time code generator
Reference signal
REF IN
TC IN
TC OUT
TC IN
TC OUT
TC IN
REF OUT
First AJ-D92 unit
Second AJ-D92 unit
Third AJ-D92 unit
GENLOCK IN
GENLOCK IN
GENLOCK IN
Camera
Camera
Camera
