101
Editing
Connecting external units
Headphones
3.5-mm stereo mini jack
• Sound is no longer heard from the speaker when the headphones are connected.
External microphone
Microphone (optional)
AG-MC200G
INPUT 1 or
INPUT 2 terminal
Microphone holder
Microphone
holder adapter
Screws for microphone
holder 6 mm
Screws for
microphone
holder 12 mm
• When attaching an external microphone to the microphone shoe, use the supplied microphone holder
and microphone holder adapter.
• When attaching the microphone holder and the microphone holder adapter, be sure to tighten the screws
firmly even though you might hear a squeaking sound.
• Use the cable clamper of the microphone holder adapter to fix the microphone cable.
