30 Jazzy 1120
2000
V I I I . O P E R A T I O N
Flashing
Bars Diagnosis Solution
10 Green High Battery Voltage Check Batteries
9 Green Solenoid Brake Fault Check Motor/Brake Wiring
8 Green Possible Controller Fault See Authorized Provider Service Center
7 Yellow Possible Joystick Fault See Authorized Provider Service Center
6 Yellow Inhibit Active Unplug Charger/Check Connections
5 Yellow Right Motor Wiring Fault Check Right Motor Wiring
4 Yellow Right Motor Disconnected Check Right Motor Wiring
3 Red Left Motor Wiring Fault Check Left Motor Wiring
2 Red Left Motor Disconnected Check Left Motor Wiring
1 Red Low Battery Voltage Check Batteries/Battery Wiring
If you cannot resolve your problem, see an authorized Pride provider or service center.
REMOTE PLUS OPTIONAL FEATURES
See figure 41 to reference the following optional features:
n Light switch: If your Jazzy is equipped with the deluxe lighting package, there is a light switch located on the
joystick controller. When your Jazzy is powered on, the light switch activates the lights.
n Turn signals: The arrow keys activate the turn signals regardless of whether or not your Jazzy is powered off
or on.
n Hazard warning: This key operates the hazard lights.
n Power elevating seat up/down (not shown): These keys eliminate the need for an additional power elevat-
ing seat switch.
