I V . T H E J A Z Z Y 1 1 2 0
2 0 0 0
Specifications
Suspension: Full suspension with Active-Trac
Rear Caster Suspension
Drive Wheels: 14 in., pneumatic (solid tires are optional)
Rear Casters: 8 in., solid, rear articulating
Anti-tip: 6 in., solid, front mounted
Maximum Speed: 6 mph
Brakes: “Intelligent Braking,” electronic regenerative, disc park brake
Ground Clearance: 3.5 in.
Turning Radius: 19.5 in.
Overall Size: Length: 39.5 in.
Width: 25.4 in.
Seating Options: Medium Back (standard)
High-back with headrest
Reclining Seat
Versa Seat
Versa Tilt
Power Elevating Option
Drive Train: Two motor, mid wheel
Batteries: Two 12-volt, Group 24 batteries (NF-22 batteries for the power
seat option)
Range: Up to 25 miles
Battery Charger: Onboard
Off-board (optional)
Electronics: 50-amp P & G Pilot Controller
70-amp P & G Remote Plus Controller
70-amp Dynamic Europa Remote Controller
Weight Capacity: 300 lbs.
Jazzy Weights: Base: 83 lbs.
Seat: 29 lbs.
Batteries: 44 lbs. each
Warranty: Lifetime limited warranty on frame
Two-year warranty on electronics
Eighteen-month warranty on drive motors
