13 Jazzy 1120
2000
I V . T H E J A Z Z Y 1 1 2 0
2 0 0 0
FREEWHEEL LEVER
For your convenience, your Jazzy is equipped with a freewheel lever. See figures 7 and 8. This lever allows you to
disengage the drive motors and maneuver the chair manually.
WARNING! Do not use your Jazzy while the drive motors are disengaged unless you are in
the presence of an attendant! Do not disengage the drive motors when your Jazzy is on an
incline. The chair could roll down on its own, causing injury!
To disengage the drive and place chair in freewheel:
1. Move the safety latch up. See figure 7.
2. Pull the freewheel lever up.
To engage the drive and take chair out of freewheel:
n Push the freewheel lever down. See figure 8.
CAUTION! It is important to remember that when your Jazzy is in freewheel mode, the
braking system is disengaged.
If a lever is difficult to move in either direction, rock your Jazzy back and forth slightly. The lever should then move
to the desired position.
Figure 7. Drive Disengaged
FREEWHEEL
LEVER
Figure 8. Drive Engaged
FREEWHEEL
LEVER
SAFETY
LATCH
SAFETY
LATCH
