Spin Fryer I12 Cooking Computer
Pitco P/N 60149505
Page 21 of 28
L22-355 Rev 1
5.10 Spin
Diagnostics
The Spin Diagnostic menu is used to determine the functionality of controller outputs and inputs.
By exercising each output and examining inputs, a determination can be made if an appliance
problem is controller related. In the diagnostic menu, product keys are assigned specific inputs or
outputs.
All outputs in the ON state should produce 22VDC at the appropriate pins on the controller
connector. Controller inputs can be verified by the on or off state of the indicator above the product
key. This section details the process of checking each input and output.
With display showing
press product key 9. The screen will show
[SPIN][DIAGNOST]
The following list describes the function of each key in the spin diagnostic mode.
Function Description
Button
5.10.1 Motor
On/Off
Toggles spin motor on and off.
L
5.10.2 Motor Speed - Increase
Increases the spin motor’s speed in 10 RPM
increments up to a maximum of 500 RPM.
1
5.10.3 Motor Speed Decrease
Decreases the spin motor’s speed in 10 RPM
increments up to a minimum of 60 RPM.
2
5.10.4 Spin
Direction
Toggles the motor’s spin direction from spinning
clockwise to counter-clockwise or vice-verse. To be
used if object becomes stuck during spinning.
3
5.10.5 Door
Open
Activates the indicator light to show the door’s current
position.
5
5.10.6 Cook Position Indicator
Activates the indicator light to show the basket lift’s
current position. Shows CLOSED if not in the stated
position.
6
5.10.7 Load Position Indicator
Activates the indicator light to show the basket lift’s
current position. Shows CLOSED if not in the stated
position.
7
5.10.8 Spin Position Indicator
Activates the indicator light to show the basket lift’s
current position. Shows CLOSED if not in the stated
position.
8
5.10.9 Basket Lift Position (Cook)
Moves the basket lift into the cook position.
9
5.10.10 Basket Lift Position (Load)
Moves the basket lift into the load position.
0
5.10.11 Basket Lift Position (Spin)
Moves the basket lift into the spin position.
R
Note: LSW – Limit Switch. This is the black collar located on the basket lift actuator.
Press
the display will return to
.
