TECHNICAL SPECIFICATIONS
Applications
Multiple RS-232 Sync or Async DCE or DTE
devices sharing one RS-232 DCE or DTE link
Capacity
One to Six RS-232 Sync or Async DTE or DCE
devices One RS-232 DCE or DTE Master Channel
Data Format
Data transparent at all data rates
Data Rates
Up to 76,800bps
Timing
Internal: DIP switch selectable
Normal: From Modem
External: Clock provided on any Sub-Channel
Anti-streaming
Automatic:Selectable timeout intervals or disable
Terminal Service Modes
Scanning Mode: .. Channels are continuously
scanned for activity on a
sequential basis.
Priority Mode: ...... Channels are simultaniously
monitored channel one has
highest access
Sub-Channel Interface
EIA RS-232 female connectors (DB-25)
Master Interface
EIA RS-232 female connector (DB-25)
Front Panel
Indicators: . Power, Send Data, Receive Data, Clock
Fallback, Sub-Channel Active, Sub-
Channel Stream
Switches: .. Enable/Disable each Sub-Channel
Power Source
100-120/200-240 Vac, 50 to 60 Hz, 0.16/0.08 A,
Switch Selectable
Environmental
Operating Temp: .. 32° to 122°F (0° to 50°C)
Relative Humidity: 5 to 90% non-condensing
Altitude: ................. 0 to 10,000 feet
Dimensions
Height: .... 1.75 inches (4.44 cm)
Width: ..... 17.00 inches (43.18 cm)
Length: ... 11.00 inches (18.93 cm)
Weight
4.5 lbs (2.1 Kg)
