Patton electronic 3060/V24 User Manual
Page 16
3060/V24
102001UA
2-8
I
NSTALLATION
A
ND
O
PERATIONS
M
ANUAL
S
ETUP
& I
NSTALLATION
P
ATTON
E
LECTRONICS
C
O
.
FACTORY Test Jumpers (JP1, JP2 and JP3)
The three test jumpers JP1, 2 and 3, must be installed for the unit to properly function. These
jumpers are used in the manufacture and test of the product prior to shipment.
