Patton electronic 3060/V24 User Manual
Page 11
3060/V24
102001UA
2-3
S
ETUP
& I
NSTALLATION
P
ATTON
E
LECTRONICS
C
O
.
I
NSTALLATION
A
ND
O
PERATIONS
M
ANUAL
RTS To CTS Delay (SW22-1,2,3)
If a CTS delay is desired, set SW22-1, 2 and 3 to the required value as indicated below.
SW22-1
SW22-2
SW22-3
Time
ON
ON
ON
No Delay
OFF
ON
ON
1mS
ON
OFF
ON
2mS
OFF
OFF
ON
4mS
ON
ON
OFF
9mS
OFF
ON
OFF
18mS
ON
OFF
OFF
36mS
OFF
OFF
OFF
72mS
Anti-Streaming (SW21-1,2,3)
The maximum data block size is user selectable via switch SW21- 1, 2 and 3. As shown
below eight block sizes are provided to the user. To disable anti-streaming set SW23-3 to the
OFF
OFF
OFF
OFF
OFF
position. The maximum block size is normally defined at the time of installation.
SW21-1
SW21-2
SW21-3 CLOCKS
ON
ON
ON
1024
OFF
ON
ON
2048
ON
OFF
ON
4096
OFF
OFF
ON
16 K
ON
ON
OFF
64 K
OFF
ON
OFF
256 K
ON
OFF
OFF
1 MEG
OFF
OFF
OFF
2 MEG
Receive Data Mode (SW23-4)
Setting switch SW23-4 to
ON
ON
ON
ON
ON
sets the 3060/V24 (CTS MD-V.24/TCB) into the Gated Mode.
Only the Sub-Channel that is currently active will receive the data from the master port. Setting
position 4 to
OFF
OFF
OFF
OFF
OFF
enables the Broadcast mode. Receive Data from the Master Port is sent to
all Sub-Channels.
