APPENDIX

Interface Pins Supported

Typical Tail Circuit Configuration

Typical Application

DB-25 RS-232

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

Shield (common)

Transmit Data (from DTE)

Receive Data (from DCE)

Request to Send (from DTE)

Clear To Send (from DCE)

Data Set Ready (from DCE)

Signal Ground (common)

Data Carrier Detect (from DCE)

+ Voltage

- Voltage

Transmit Clock (from DCE)

Receive Clock (from DCE)

Data Terminal Ready (from DTE)

External Transmit Clock (from DTE)

Host

TXC-15

RXC-17

Modem

Modem

3060/V24

XTXC-24

RXC-17

RXC-17

TXC-15

RXC-17

TXC-15

Terminal

Buffer

External

TX Clocking

Slave

TX Clocking

Modem

XTXC-24

Slave

TX Clocking

XTXC-24

Data

Internal

TX Clocking

Data

Data

Data

Data

Data

Data

Modem

3060/V24

RS-232

RS-232

RS-232

RS-232

Leased

or

Dial Line

Leased

or

Dial Line

Leased

or

Dial Line

RS-232 MODEM

RS-232 MODEM

RS-232 MODEM
