Getting to know your up-800 data projector, Left side features, Front features – PLUS Vision UP-800 User Manual
Page 7: Rear features, E – 7, Power switch
E – 7
PC CONTROL
VIDEO IN
S-VIDEO
VIDEO
L/MONO · AUDIO · R
AUDIO IN
AUDIO OUT
RGB IN
RGB OUT
Getting To Know Your UP-800 Data
Projector
Rear Feet
Left Side Features
Terminal Panel
Front Features
AC Input
Connect the supplied power
cable’ s three-pin plug here.
Remote Sensor
Slot for Kensington MicroSaver
Security System
Power Switch
Rear Features
STANDBY
STANDBY
MENU
SELECT
ENTER
ADJUST
PLUS
PC CONTROL
VIDEO IN
S-VIDEO
VIDEO
L/MONO ·
AUDIO ·
R
AUDIO IN
AUDIO OUT
RGB IN
RGB OUT
Monaural Speaker(2W)
Cooling Fan
Top features
Zoom Ring Rever
Lens and lens Cap
Focus Ring
Remote Sensor
Adjusters
Ventilation
