59
4
Chapter 4 Adjustments and settings for recording
(continued)
Set the marker and user boxes to superimpose on the output
signals from the VIDEO OUT connector by using the
respective items on the screen
(SYSTEM SETTING page) of the menu.
USER BOX WIDTH 1
:
13
:
100
For setting the horizontal width of the user
box.
USER BOX
HEIGHT 1
:
13
:
100
For setting the vertical height of the user
box.
USER BOX H POS –50
:
+00
:
+50
For setting the horizontal position of the user
box center.
USER BOX V POS –50
:
+00
:
+50
For setting the vertical position of the user
box center.
Item
Variable
range
Remarks
VIDEO OUT
CENTR MARK OFF
1
2
3
4 For setting the center marker to be
superimposed on the output signals of the
VIDEO OUT connector.
OFF: The center marker is not displayed.
1:
+ (large)
2: Center blank (large)
3: + (small)
4: Center blank (small)
VIDEO OUT
SAFETY MARK OFF
1
2 For setting the type of safety marker frame
to be superimposed on the output signals of
the VIDEO OUT connector.
OFF: The safety marker frame is not
displayed.
1: Box
2: Corner frames
VIDEO OUT FRM
MARK ON
OFF For superimposing the frame marker on the
output signals from the VIDEO OUT
connector.
ON: To superimpose
OFF: Not to superimpose
VIDEO OUT USER
BOX ON
OFF For superimposing the user box on the
output signals from the VIDEO OUT
connector.
ON: To superimpose
OFF: Not to superimpose
O It is not superimposed when the VIDEO
OUT switch is set to the SD-SDI or the
VBS position.
SAFETY AREA 80%
:
90%
:
100%
For setting the size of the safety marker.
It is possible to set the size by units of 1%
with a fixed ratio between of width and
height.
FRM SIG 4:3
13:9
14:9
VISTA For setting the frame marker.
The VISTA setting is 16:8.65.
O The user box can be displayed in any position as a box-
type cursor.
O When the DOWNCON MODE item on the DOWNCON
SETTING screen is set to LT-BOX or S-CROP, the frame
marker and the safety marker are not displayed.
O Settings in the SAFETY AERA item and the FRM SIG
item are interlinked with the respective connectors of
VIDEO OUT, MON OUT, and REMOTE.
O Settings for the respective items of USER BOX WIDTH,
USER BOX HEIGHT, USER BOX H POS, and USER
BOX V POS are interlinked with the VIDEO OUT
connector and the MON OUT connector.
