Figure 16 — Main BIOS Setup menu.
The first screen you’ll see is the Main menu.
System Time and System Date
These values are changed by moving to each field and typing in the desired entry. The TAB key
moves from hours to minutes to seconds, or from months to days to years.
Legacy Diskette A:
This field specifies the type of floppy disk installed as drive A:. Possible settings are
1.44/1.25 MB, 3
1 ⁄
2
; 360 KB; 1.2 MB; 720 KB; and Disabled. The default is 1.44/1.25 MB, 3 1 ⁄
2
.
Primary Master and Primary Slave Sub-Menus
These fields are headings for menus that allow entering complete disk drive information.
Usually, if your hard disk has not been defined, you will press at the IDE Adapter 0
Master sub-menu. There you can select Autotype Fixed Disk to allow the system to detect the
drive type automatically. The entry in the Main menu shows the drive selected.
Memory Cache Sub-Menu
The term memory cache refers to the technique of caching BIOS images.
UBE Shadow Control Sub-Menu
The options under this menu enable up to three user BIOS extensions and specify a source,
destination shadow address, and size.
Chapter Five: BIOS Setup
17
System Time: [16: 17: 18]
System Date: [03/01/99]
Legacy Diskette A: [Not installed]
ᮣ Primary Master: (1705MB)
ᮣ Primary Slave: (None)
ᮣ Memory Cache:
ᮣ Boot Options:
ᮣ UBE Shadow Control:
ᮣ Boot-time Diagnostic Screen: [Enabled]
System Memory: 640 KB
Extended Memory: 64512 KB
Item Specific Help
, , or
selects field.
F1 Help
↑↓
Select Item -/+ Change Values F9 Set Defaults
ESC Exit ↔ Select Menu Enter Select ᮣ Sub-Menu F10 Save and Exit
