Panasonic KX-FT21RS - Manual (Page 77)

Code Function Set Value Effective Range Default Remarks
718 Receive speed select 1:9600BPS
2:7200BPS
3:4800BPS
4:2400BPS 1~4 9600 BPS Adjusts the speed to start training during FAX
reception.
719 Ringer off in TEL/FAX
mode 1:ON 2:OFF 1, 2 ON Sets the ringer switch off when a call is
received in the TEL/FAX mode.
721 Pause tone detect 1:ON 2:OFF 1, 2 ON Selects the tone detection for pauses in
dialing.
722 Redial tone detect 1:ON 2:OFF 1, 2 ON Selects the tone detection mode after
redialing.
763 CNG detect time 1:10 sec 2:20 sec
3:30 sec 1, 2, 3 20 sec Selects the CNG detection time of friendly
reception.
771 T1 timer 1:35 sec 2:60 sec 1, 2 35 sec Sets a higher value when the response from
the other party needs more time during FAX
transmission.
774 T4 timer 00~99 (×100ms) 00~99 00
815 Sensor check Press "START".
882 Journal 3 list See 2.6.1. PRINTOUT EXAMPLE.
844 Original setting 1:NORMAL
2:LIGHT
3:DARKER 1, 2, 3 NORMAL Use this feature when you need to transmit
and copy a document with very faint writing or
very dark writing.
2.4.5. SERVICE MODE SETTINGS (Example of a printed out list)
Note:
The above values are the default values.
77
KX-FT21RS
