Ref.
No.
Part No. Part Name & Description Remarks
C114 ECUV1C104KBV 0.1
C115 ECUV1H332KBV 0.0033
C116 ECUV1H103KBV 0.01
C117 ECUV1H102KBV 0.001
C120 ECEA1CK101 100 S
C121 ECUV1H102KBV 0.001
C122 ECEA1HKS4R7 4.7
C125 ECUV1C104KBV 0.1
C126 ECUV1C104KBV 0.1
C127 PQCUV1C474KB 0.47
C201 ECEA1EK470 47 S
C202 ECUV1H103KBV 0.01
C203 ECUV1H103KBV 0.01
C204 ECUV1H103KBV 0.01
C205 ECEA1CKS100 10 S
C206 ECUV1C104KBV 0.1
C207 ECUV1C104KBV 0.1
C208 ECUV1H471JCV 470P
C209 ECUV1H472KBV 0.0047
C211 ECUV1H471JCV 470P
C212 ECUV1H223KBV 0.022 S
C213 ECEA1CK101 100 S
C215 ECUV1H560JCV 56P
C220 ECUV1C104KBV 0.1
C226 ECUV1C104KBV 0.1
C227 ECUV1H103KBV 0.01
C228 ECUV1H103KBV 0.01
C229 ECUV1H103KBV 0.01
C231 ECEA1EK470 47 S
C232 ECUV1H103KBV 0.01
C233 ECUV1H103KBV 0.01
C235 ECUV1C104KBV 0.1
C240 PQCUV1H102J 0.001 S
14.4. OPERATION BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
PCB3 PFLP1196BXZ OPERATION BOARD ASS´Y (RTL)
(IC)
IC1 PQVIMC4051BF IC
(TRANSISTORS)
Q1 PQVTDTA143EU TRANSISTOR(SI)
Q2 PQVTDTA143EU TRANSISTOR(SI)
Q3 PQVTDTA143EU TRANSISTOR(SI)
(DIODES)
D1 1SS131 DIODE(SI)
(CONNECTORS)
CN1 PFJS11A13Z CONNECTOR, 11PIN
(LIQUID CRYSTAL DISPLAY )
Ref.
No.
Part No. Part Name & Description Remarks
CN3 PFAVM190 LIQUID CRYSTAL DISPLAY
(PHOTO ELECTRIC TRANSDUCERS)
PS1 CNA1006N PHOTO ELECTRIC TRANSDUCER
PS2 CNA1006N PHOTO ELECTRIC TRANSDUCER
(RESISTORS)
J18 ERJ3GEY0R00 0
J30 ERDS1TJ470 0
R2 ERJ3GEYJ103 10k
R3 ERJ3GEYJ103 10k
R4 ERJ3GEYJ103 10k
R5 ERJ3GEYJ103 10k
R7 ERJ3GEYJ103 10k
R10 ERJ3GEYJ103 10k
R11 ERJ3GEYJ271 270
R12 ERJ3GEYJ563 56k
R13 ERJ3GEYJ103 10k
R14 ERJ3GEYJ471 470
R15 ERJ3GEYJ103 10k
R16 ERJ3GEYJ471 470
R17 ERJ3GEYJ103 10k
R18 ERJ3GEYJ471 470
R19 ERJ3GEYJ103 10k
R20 ERJ3GEYJ471 470
R21 ERJ3GEY0R00 0
R28 ERJ3GEYJ103 10k
R30 ERJ3GEYJ681 680
(CAPACITORS)
C1 ECUV1H104ZFV 0.1 S
C2 ECEA1AKS221 220
C6 ECUV1C224ZFV 0.22
(SWITCHES)
SW1 EVQ11Y05B SPECIAL SWITCH
SW2 EVQ11Y05B SPECIAL SWITCH
SW3 EVQ11Y05B SPECIAL SWITCH
SW5 EVQ11Y05B SPECIAL SWITCH
SW6 EVQ11Y05B SPECIAL SWITCH
SW7 EVQ11Y05B SPECIAL SWITCH
SW8 EVQ11Y05B SPECIAL SWITCH
SW10 EVQ11Y05B SPECIAL SWITCH
SW11 EVQ11Y05B SPECIAL SWITCH
SW12 EVQ11Y05B SPECIAL SWITCH
SW13 EVQ11Y05B SPECIAL SWITCH
SW14 EVQ11Y05B SPECIAL SWITCH
SW15 EVQ11Y05B SPECIAL SWITCH
SW16 EVQ11Y05B SPECIAL SWITCH
SW17 EVQ11Y05B SPECIAL SWITCH
SW18 EVQ11Y05B SPECIAL SWITCH
SW19 EVQ11Y05B SPECIAL SWITCH
SW20 EVQ11Y05B SPECIAL SWITCH
SW21 EVQ11Y05B SPECIAL SWITCH
SW22 EVQ11Y05B SPECIAL SWITCH
SW23 EVQ11Y05B SPECIAL SWITCH
SW24 EVQ11Y05B SPECIAL SWITCH
SW25 EVQ11Y05B SPECIAL SWITCH
