Panasonic KX-FT21RS - Manual (Page 163)

Ref.
No.
Part No. Part Name & Description Remarks
(PHOTO ELECTRIC TRANSDUCERS)
PC1 PQVIPS2532-1 PHOTO ELECTRIC TRANSDUCER S
PC5 PQVIPC814K PHOTO ELECTRIC TRANSDUCER
(THERMISTOR)
POS1 PFRT002 THERMISTOR
(RELAY)
RLY1 ATXD20328 RELAY
(VARISTORS)
SA1 PQVDRA311PT3 VARISTOR S
SA2 PFRZ001Z VARISTOR
(SWITCHES)
SW201 PFSH1A03Z SWITCH
SW202 ESE14A211 SWITCH
(TRANSFORMERS)
T101 PFLT8E003 TRANSFORMER
T102 PFLT8E004 TRANSFORMER
(VARISTORS)
ZNR1 ERZVA7D121 VARISTOR
ZNR2 ERZVA7D121 VARISTOR
(RESISTORS)
C214 ERJ3GEY0R00 0
C219 ERJ3GEY0R00 0
C234 ERJ3GEY0R00 0
J402 ERJ3GEY0R00 0
J403 ERJ3GEY0R00 0
J404 ERJ8GEY0R00 0
R1 ERJ3GEYJ222 2.2k
R4 ERDS1TJ561 560
R5 ERJ3GEYJ821 820
R6 ERDS2TJ104 100k
R7 ERDS2TJ222 2.2k
R12 PQ4R10XJ123 12k S
R13 PQ4R10XJ562 5.6k S
R15 ERDS1TJ330 33 S
R17 ERJ3GEYJ333 33k
R18 ERDS1TJ473 47k
R19 ERDS1TJ473 47k
R22 ERJ3GEYJ104 100k
R102 ERJ3GEYJ102 1k
R103 ERJ3GEY0R00 0
R104 ERJ3GEYJ623 62k
R105 ERJ3GEYJ471 470
R106 ERJ3GEYJ122 1.2k
Ref.
No.
Part No. Part Name & Description Remarks
R107 ERJ3GEYJ623 62k
R108 ERJ3GEYJ121 120
R109 ERJ3GEYJ122 1.2k
R110 ERJ3GEY0R00 0
R111 ERJ3GEYJ823 82k
R112 ERJ3GEY0R00 0
R113 ERJ3GEYJ823 82k
R114 ERJ3GEYJ222 2.2k
R115 ERJ3GEYJ223 22k
R116 ERJ3GEYJ223 22k
R117 ERJ3GEYJ333 33k
R118 ERJ3GEYJ114 110k
R119 ERJ3GEYJ154 150k
R120 ERJ3GEY0R00 0
R121 ERJ3GEYJ103 10k
R122 ERJ3GEYJ153 15k
R124 ERJ3GEYJ473 47k
R201 ERJ3GEYJ331 330
R202 ERJ3GEYJ152 1.5k
R203 ERJ3GEYJ152 1.5k
R204 ERJ3GEYJ153 15k
R205 ERJ3GEYJ153 15k
R206 ERJ3GEY0R00 0
R207 ERJ3GEYJ331 330
R208 ERJ3GEYJ473 47k
R209 ERJ3GEYJ822 8.2k
R210 ERJ3GEYJ154 150k
R211 ERJ3GEYJ154 150k
R212 ERJ3GEYJ562 5.6k
R217 ERJ3GEYJ153 15k
R218 ERJ3GEYJ823 82k
R225 ERJ3GEY0R00 0
R230 ERJ3GEYJ103 10k
R231 ERJ3GEYJ622 6.2k
R232 ERJ3GEYJ472 4.7k
R233 ERJ3GEYJ101 100
R234 ERJ3GEYJ472 4.7k
R235 ERJ3GEYJ101 100
R250 ERJ3GEYJ222 2.2k
R251 ERJ3GEYJ222 2.2k
R252 ERJ3GEYJ222 2.2k
(CAPACIT0RS)
C2 ECKD2H681KB 680P S
C3 ECKD2H681KB 680P S
C4 ECUV1H102KBV 0.001
C5 PQCUV1H472KB 0.0047
C8 ECEA1HKS4R7 4.7
C9 ECEA1CKS100 10 S
C12 ECQE2E224JZ 0.22 S
C13 ECQE2E104KZ 0.1 S
C14 PQCUV1H105JC 1 S
C101 ECUV1H102KBV 0.001
C105 PQCUV1C224KB 0.22
C106 ECEA1HKS4R7 4.7
C107 ECUV1C104KBV 0.1
C109 ECUV1H330JCV 33P
C111 ECUV1C104KBV 0.1
C112 PQCUV1C224KB 0.22
C113 ECUV1H330JCV 33P
163
KX-FT21RS
