Chapter 3: Starting Your PowerStation
PowerStation Connectors
PA PowerStation User Guide
3-11
To Print to a Port Configured for Downloading
If you plan to print to a port that is configured for downloading, you will
need to reconfigure the port before you can print to it. To reconfigure the
port, complete the following steps:
1
Disable downloading for that port.
2
Restart the PA PowerStation.
Note Restarting the PowerStation allows MODE.COM to reset the
communication settings for that port.
3
Select Settings from the Main Menu.
4
Choose TCP/IP from the selections displayed.
5
Select Net Setup from the menu.
Important The configuration may already be set to Download Only.
If not, continue with step 6. Otherwise, skip to step 8.
6
Depending on how your PA PowerStation is configured, select the
appropriate Net (Net 1, Net 2, or Net 3).
7
Choose Download Only from the options displayed.
8
Continue to Back out until you reach a prompt that indicates the
TCP/IP configuration has changed and asks whether you want to
Reboot.
9
Choose Yes to reboot the PA PowerStation. This will save your
changes.
Ethernet Port
The PA PowerStation has an Ethernet RJ45 port with an Intel 82551ER
10/100 Mbps base-T controller that allows you to connect the PowerStation
to a Local Area Network.
Table 3-4: Ethernet Pinouts
Pin#
Signal
1
TX+
2
TX-
3
RX+
4
N/C
5
N/C
6
RX-
7
N/C
8
N/C
