Connecting the DR500 to Your Stereo System
To connect the DR500 to a stereo system, refer to the figure below and the following instructions.
1. Make sure the stereo amplifier is OFF and the volume is turned completely down.
2. Connect the RCA stereo cables to the L(eft) and R(ight) STEREO jacks on the back
of the DR500.
3. Connect the other end of the RCA cables to any high-level input on your stereo
equipment EXCEPT the phonograph input.
Remember to match left and right channels.
Do not connect the RCA cables from the DR500 to the PHONO input of audio
equipment. Any line level input such as AUX, CD, DAT, TAPE, VIDEO, or
VCR can be used for the DR500 output.
4. Plug the DR500 into an AC outlet.
5. Continue on to Section 3: Basic Operations.
