41
Specifications
[GENERAL]
Power requirements: DC 12V (11.0V to 17.0V)
Power consumption: 17W
Operating temperature: 0 to 40 C
Storage temperature: –20 to +60 C
Operating humidity: Less than 85% (relative humidity)
Continuous operating time: Approx. 120 min. (continuous recording time using the
TRIMPAC14 made by Anton Bauer)
Dimensions: 123(W) x 190(H) x 292(D) mm (excluding grip)
Weight: Approx. 3 kg (main unit only)
[CAMERA UNIT]
Pickup device: 1/2-inch IT type CCD (410,000 pixels)
System: RGB 3-CCD system
Total number of pixels: 811(H) x 508(V)
Number of effective pixels: 768(H) x 494(V)
Spectral system: f/1.4 prism system
Internal filters: 1: 3200K (clear)
2: 5600K + 1/8N
3: 5600K
4: 5600K + 1/64ND
Quantizing: 10 bits, non-linear
Sampling frequency: 14.31818 MHz (4 fsc)
Digital signal processing: 28.63636 MHz (8 fsc)
Horizontal drive frequency: 28.63636 MHz (8 fsc)
Programmable gain: 3 positions (L, M and H) selected from 0, 3, 6, 9, 12, 15, 18,
21, 24, 30, 36 dB
Shutter speed Preset: 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000
Variable: 1/60.3 to 1/250.0
Lens mount: Bayonet type
Sensitivity: f/11 (2000 lux)
Minimum subject brightness: 0.5 lux (at f/1.4 + 36 dB)
Video S/N ratio: 62 dB (standard)
Horizontal resolution: Over 800 lines (at center) (CAM OUT connector)
Registration: Less than 0.05% (total area, lens distortion excluded)
Geometric distortion: Negligible (lens distortion excluded)
indicates safety information.
