Rear jack & back case parts assembly, Mpl-8 – Panasonic AG-HMC151E User Manual
Page 9
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
1
VGP6237
BATTERY CASE
1
2
VGU0D20
BATTERY RELEASE LEVER
1
3
VMP9164
BATTERY LOCK ANGLE
1
4
VMB4209
SPRING
1
5
VGL1284
P2 CARD PANEL LIGHT
1
6
VGP623
P2 CARD COVER
7
VGQ0A59
SHAFT COVER
1
8
VMB4210
SPRING
1
9
VSC6070
P2 SHIELD PLATE R
1
12
VYF3229
P2 CARD DOOR U
1
13
VXU1676
MODE DIAL KNOB U
1
14
VGU9219
CAMERA/VCR BUTTON
2
15
VGL1012
MODE PANEL LIGHT
3
17
VSC6094
REAR JACK SHIELD ANGLE
1
18
VYK2V02
REAR JACK CASE U
1
19
VMP9166
REAR JACK PLATE
1
20
VGU0D22
CONNECTOR CAP
1
21
K2HZ105E0011 BNC CONNECTOR
1
22
VSC6095
REAR JACK SHIELD PLATE
1
23
VGQ0A58
BATTERY LOCK PIECE
1
101
XQN2+BJ5FJK
SCREW
12
102
XQN16+BJ4FJK SCREW
3
103
XQN2+B4FJK
SCREW
11
104
VHN0382
NYLON NUT
1
105
XQN2+B4FN
SCREW
2
106
XYN2+J6FJ
SCREW
3
E7
VEP001X1A
REAR JACK P.C.BOARD
1
E8
VEP04939A
REAR JACK 2 P.C.BOARD
1
E16
VEP01A07A
BATTERY P.C.BOARD
1
E20
VEP001W5A
MODE SW P.C.BOARD
1
REAR JACK & BACK CASE PARTS ASSEMBLY
MPL-8
