Side case parts assembly, Mpl-6 – Panasonic AG-HMC151E User Manual
Page 7
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
Ref.No.
Part No.
Part Name & DescriptionPcs
Remarks
1
VYK2V05
SIDE CASE R 1 U
1
2
VMG1286
CUSHION RUBBER
1
3
VMZ3757
PROTECTION SHEET A
1
4
VGQ0A73
CAM OP BACKUP CASE
1
5
VGU0D28
FOCUS KONB
1
6
VGU0D29
CAM OP BUTTON
1
7
VGU0D34
ND KNOB
1
8
VMB4017
SPRING
1
9
VGQ0A76
IRIS HOLDER
1
10
VGU9933
IRIS DIAL
1
11
VGQ6917
MENU ROTATION KNOB SHEET
1
12
VGU0D30
LCD BUTTON A
1
13
VGU0D31
LCD BUTTON B
1
14
VGU0D32
MODE SW KNOB
2
15
VGU0D33
DISPLAY BUTTON
1
16
VGQ0B05
CLUTCH HOLDER
1
17
VGU0D51
CLUTCH HOLDER
1
18
VMP9185
CLUTCH KNOB HOLD ANGLE
1
19
VMP9186
CLUTCH PLATE
1
20
VGQ0A77
LCD HOOK PIECE
1
21
VYQ4490
IR SENSOR COVER U
1
22
VGU0D35
AWB BUTTON
1
23
VGU0D38
IRIS BUTTON
1
24
VGU9894
SLIDE KNOB
4
25
VGH4857
SLIDE KNOB SHEET
4
26
VWJ16G6054L0 PRINTED FLEXIBLE CABLE
1
27
VWJ06G6033L0 PRINTED FLEXIBLE CABLE
1
28
VWJ06G6045L0 PRINTED FLEXIBLE CABLE
1
30
VMT1849
GASKET
1
32
VMT1952
AWB BUTTON SHEET
1
33
VMT1953
BUTTON MUFFLING SHEET
4
34
VWJ50G7165L0 PRINTED FLEXIBLE CABLE
1
35
J0ZZZ0000073 GASKET
2
101
XQN2+BJ4FJK
SCREW
6
102
XQN2+B4FN
SCREW
13
104
XQN2+B4FJK
SCREW
5
E4
VEP001W7B
R SIDE P.C.BOARD
1
E5
VEP001W1A
CAM OP P.C.BOARD
1
E19
VEP001X8A
TOGGLE SW P.C.BOARD
1
E25
VEP001X9A
TOGGLE SW P.C.BOARD
1
SIDE CASE PARTS ASSEMBLY
MPL-6
