Ref.No. Part No. Part Name & DescriptionPcs Remarks Ref.No. Part No. Part Name & DescriptionPcs Remarks
E17 VEP001V9A MENU P.C.BOARD 1
1 L5EDDXM00003 ELECTRIC VIEW FINDER 1 E23 VEP001W0A TOP CON P.C.BOARD 1
2 VGQ0A84 LCD CASE 1 E24 VEP001W4A EVF CON P.C.BOARD 1
3 VMX3685 P.C.BOARD SPACER 1
4 VGQ7088 LCD MASK SHEET 1
5 VMZ3799 EVF SHEET 1
6 VGQ0A85 LCD CASE COVER 1
7 VMP9179 LCD CASE ANGLE 1
8 VWJ1805 PRINTED FLEXIBLE CABLE 1
9 VYK1V99 EYE CAP U 1
10 VGP6251 EVF CASE 1
11 VQL1U26 SUNLIGHT CAUTION LABEL 1
12 VMG1286 CUSHION RUBBER 2
13 VDK0187 HELICOID CAM TUBE 1
14 VGQ0A82 ADJUST RING 1
15 VMT1931 RING SPACER 2
16 VGQ0A83 EYE CAP BASE 1
17 VKC0621 EVF HINGE 1
18 VGQ0A87 EVF HINGE COVER 1
19 VXW0991 EVF LENS 1
20 VKH0437 HANDLE 1
21 VJF1421 SHOE 1
22 VMC1697 SPRING 1
23 VGU0D27 SLIDE SWITCH KNOB 2
24 VMP9170 SLIDE SW KNOB PLATE 2
25 VGH4857 SLIDE KNOB SHEET 2
26 VYK2U82 MIC CASE 1U 1
27 VYK1R40 MIC U 1
28 VMZ3775 ABSORPTION SHEET 1
29 VMG1732 MIC DUMPER RUBBER 1
30 VMZ3776 ABSORPTION SHEET 2
31 VWJ10G6065L0 PRINTED FLEXIBLE CABLE 1
32 VMT1767 MIC DUMPER SHEET 1
33 VKH0439 HANDLE STAY 1
34 VMP9171 PLATE 1
35 VGQ0A66 HANDLE STAY COVER 1
36 VWJ24G7060L0 PRINTED FLEXIBLE CABLE 1
37 VGQ0A64 HANDLE GRIP 1
38 VGU9988 REC BUTTON 1
39 VMZ3474 LCD INSULATOR 1
40 VMT1948 GASKET 2
41 VYK2U99 VF CASE R 1 U 1
42 VGU0D41 MENU MODE KNOB 1
43 VWJ10G7060L0 PRINTED FLEXIBLE CABLE 1
44 VGM2283 TOP CASE 1
45 VMZ3712 SPEAKER NET 1
47 L0AA02A00054 SPEAKER 1
48 VMP9196 SPEAKER ANGLE 1
49 VMP9233 TOP CON ANGLE 1
50 VMG1286 CUSHION RUBBER 1
51 VGP6249 VF CASE L 1
 52 VGN1B93 RATING LABEL 1 FOR AG-HMC150P
 52 VGN1B94 RATING LABEL 1 FOR AG-HMC151E
 52 VGN1B95 RATING LABEL 1 FOR AG-HMC152EN
 52 VGN1B96 RATING LABEL 1 FOR AG-HMC153MC
53 VMT1767 MIC DAMPER SHEET 1
101 XQN16+C3FJ SCREW 4
102 XQN2+BJ5FJK SCREW 13
103 XQN2+B4FN SCREW 21
104 XSN2+4FC SCREW 1
105 XSS2+4FJK SCREW 4
106 XQN2+BJ4FJ SCREW 4
107 XWG2FJ WASHER 2
108 XQN2+B4FJK SCREW 11
109 XYN26+J6FJ SCREW 5
110 XYN2+F5FJ SCREW 1
111 XQN2+BJ5FN SCREW 2
112 XYN2+F6FJ SCREW 2
113 XYN26+J6FJK SCREW 2
E14 VEP04940A HANDLE P.C.BOARD 1
E15 VEP001X7A REMOCON F P.C.BOARD 1
EVF PARTS ASSEMBLY
MPL-4
