Jazzy 1105/RevH/Feb03 www.pridemobility.com 29
V I I I . O P E R A T I O N
BARS DIAGNOSIS SOLUTION
10 Green High Battery Voltage Check Batteries
9 Green Solenoid Brake Fault Check Motor/Brake Wiring
8 Green Possible Controller Fault See Authorized Provider Service Center
7 Yellow Possible Joystick Fault See Authorized Provider Service Center
6 Yellow Inhibit Active Unplug Charger/Check Connections
5 Yellow Right Motor Wiring Fault Check Right Motor Wiring
4 Yellow Right Motor Disconnected Check Right Motor Wiring
3 Red Left Motor Wiring Fault Check Left Motor Wiring
2 Red Left Motor Disconnected Check Left Motor Wiring
1 Red Low Battery Voltage Check Batteries/Battery Wiring
Charger Inhibit Plug Connection
The charger inhibit connector on the utility tray is coded with colored dots. The dots are positioned so that
you align the flat side of the male connector with the flat side of the female connector before making the
connection.
CAUTION! Failure to properly align the connectors can result in damage to the controller, the
charger harness, and the connectors.
n Red bars indicate that you should charge the batteries as soon as possible, because low battery voltage
may cause your Jazzy to become inoperative.
Note: When the batteries approach a discharged state, the first red bar will begin to slowly flash, reminding
you the batteries need to be charged immediately!
Thermal Rollback
The Pilot controller is equipped with a thermal rollback circuit. This circuit monitors the temperature of the
motors and the controller. In the event that the motors or the controller become excessively hot (above 122°
F), the controller reduces the motor voltage. For every degree above 122° F, the controller reduces the
voltage by 5 volts. This reduces your Jazzy’s speed and allows the electrical components to cool down.
When the temperature returns to a safe level, your Jazzy 1105 resumes its normal speed.
Trouble Codes
In addition to indicating the current state of battery charge, the battery condition meter can also indicate
possible problems with your Jazzy 1105. The battery condition meter has ten individual bars. The bars
provide information by the number of bars that are flashing. If the meter is flashing rapidly, the controller
may be indicating a fault. For instance, the very first red bar flashing rapidly indicates the battery voltage is
nearly depleted. The following is a list of the possible errors signified by the rapidly flashing meter.
If you cannot resolve your problem, see an authorized Pride provider or service center.
