I V . T H E J A Z Z Y 1 1 0 5
FREEWHEEL LEVERS
For convenience, your Jazzy 1105 is equipped with two freewheel levers. These levers allow you to disengage
the drive motors and maneuver the chair manually.
WARNING! Do not use your Jazzy while the drive motors are disengaged unless you are in the
presence of an attendant! Avoid placing the Jazzy 1105 in freewheel on an incline as the unit
could roll on its own, causing injury.
CAUTION! It is important to remember that when your Jazzy is in freewheel mode, the braking
system is disengaged.
To engage or disengage the freewheel feature:
1. Locate the two (2) metal freewheel levers connected to the motors. See figure 4.
2. Turn the levers outward from the center of the Jazzy 1105 to disengage the drive motors.
3. Turn the levers inward toward the center of the Jazzy 1105 to engage the drive motors.
4. If a lever is difficult to move in either direction, rock the Jazzy 1105 back and forth slightly. The lever
should then move to the desired position.
Figure 4. Freewheel Levers
FREEWHEEL LEVERS
