Pride Mobility Jazzy 1105 User Manual
Page 17
Jazzy 1105/RevH/Feb03
www.pridemobility.com
17
I V . T H E J A Z Z Y 1 1 0 5
Figure 2. Jazzy 1105 Disassembled
Figure 3. Jazzy Wiring Harnesses
FOOT PLATE
SEAT
POWER BASE
(FULLY COLLAPSED)
JOYSTICK/
CONTROLLER
BATTERY CASES
CONTROLLER HARNESS CONNECTOR
MOTOR HARNESS CONNECTOR
MOTOR HARNESS CONNECTOR
CHARGER HARNESS CONNECTOR
