3. Bring the unit up tight under the boom (with the long axes parallel), sliding the All-Thread
studs past the sides of the boom to show above the boom top. Place the remaining pieces
of Uni-strut (open channel down) across the boom, onto the protruding All-Thread stud
ends. Secure firmly with a flat washer and ½” nut on each of the four All-Thread stud
ends. Looking from the end of the boom, the mounted unit should look as shown in Figure
2-8.
4. Connect the Compact Outdoor SSPA unit as directed elsewhere in this manual.
Figure 2-8: CO Mount Completed
