Operations Manual, HPA2, Compact Outdoor SSPA
208495 REV C
19
The power supplies provide universal AC input by using auto-sensing power supplies. The
AC input can operate over a range of 90-265 VAC, at 47 to 63 Hz. The power supply is also
power factor corrected, enabling the unit to achieve a power factor greater than 0.93.
The prime power vs. RF output power is summarized in Table 2-6 on the following page. An
option for 110 VAC prime power is available for the higher-powered units.
The highest output power levels, >70 W @ Ku-Band and >100 W @ C-Band should be
powered only from a 180–265 VAC source. This will keep AC line currents to safe operating
levels for the internal EMI filter and associated circuitry.
2.2.7.1 DC Input Option [MS3102E-20-29P]
The Compact Outdoor Amplifier can also be configured with a DC Input Voltage power
supply. The DC Input Voltage can range from 42-60 VDC. When using a DC input voltage the
input power connector, J7, is configured per Table 2-4. The mating connector (MS3106F20-
29S) is supplied with the unit.
2.2.8 15 VDC Output Port (J8) [MS3112E10-6S]
The 15 VDC Output, J8, is located on the bottom side of the amplifier as shown in Figure 2-3.
This provides +15 VDC and up to 1 Amp current to any external equipment. It is a 6-pin
MS-type connector (see Table 2-5 for pin-outs) and mates with MS3116F10-6P.
2.2.9 Chassis Ground Terminal
A Chassis ground terminal is provided on the bottom side of the amplifier. A ¼ - 20 threaded
terminal is provided for equipment grounding.
Pin # on J7
Connection
B +48
V
C
+48 V
D +48
V
K
-48 V
Connection
-48 V
-48 V
GND
Pin # on J7
L
M
N
Table 2-4: DC Input Connector, MS3102E-20-29P
Table 2-5: +15 VDC Output Port (J8) Pin-Outs
Pin # on J8
Connection
Pin # on J8
Connection
A
EXTERNAL FAULT IN
D
GND
B
FAULT PULLUP
E
+15V EXTERNAL
C +15V
LNA F
GND
