Operations Manual, HPA2, Compact Outdoor SSPA
208495 REV C
139
Mixing New Generation Compact Outdoor Amplifiers
with Units Manufactured Prior to 2003
Configuring redundant systems with older model Compact Outdoor amplifiers with new
generation models will require a different switch cable configuration than those shown in
Section 9. Older generation amplifiers are generally those manufactured prior to year 2003.
This switch cable can be ordered from the factory as part number 201608.
&
CONTROL
MONITOR
J4
J3
OUTPUT SAMPLE
J3
OUTPUT SAMPLE
A B
F
B
F
LINK
LINK
J5
J5
A
B
C
D
E
F
1
2
4
3
SSPA 1
SSPA 2
E
C
C
E
F
RF OUTPUT
SWITCH
&
CONTROL
MONITOR
J4
LINK
CABLE
SWITCH CABLE
A
F
J6
SWITCH
A2 (J6)
A1 (J6)
J6
SWITCH
D
Older Generation Compact Outdoor SSPA
New Generation Compact Outdoor SSPA
Figure B-1: Mixed Redundant System using New Generation and Original Compact
Outdoor Amplifiers
Appendix B: Alternate System
Configurations
