Polaris Sportsman 550 EFI - Manual (Page 138)

134
SPECIFICATIONS
* Based on EU Directive 76/432/EC
**A higher initial idle speed of 1800 RPM will occur for the first few minutes of operation.
Sportsman X2 550 EFI
Maximum Weight Capacity 735 lbs. (333 kg) (includes operator, passenger,
cargo, accessories)
Dry Weight 799 lbs. (362.4 kg)
Fuel Capacity 5.25 gal. (20 l)
Engine Oil Capacity 2 qts. (1.9 l)
Coolant Capacity 2 qts. (1.9 l)
Transmission Oil Capacity 32 oz. (948 ml)
Demand Drive Fluid Capacity 9.3 oz. (275 ml)
Rear Gearcase Oil Capacity 6.1 oz. (180 ml)
Front Rack/Storage Box Capacity 120 lbs. (54 kg)
Rear Storage Box Capacity
400 lbs. (181 kg)
Hitch Tongue Weight 150 lbs. (68 kg) (Rear box capacity and tongue
weight not to exceed 400 lbs./181 kg)
Hitch Towing Rating 1500 lbs. (680 kg) on level ground
Unbraked Trailer Towing
Capacity*
1995 lbs. (905 kg)
Overall Length 93.25 in. (237 cm)
Overall Width 47.6 in. (121 cm)
Overall Height 49.5 in. (125.7 cm)
Wheelbase 57 in. (145 cm)
Ground Clearance 11.25 in. (28.6 cm)
Minimum Turning Radius 96 in. (244 cm) unloaded
82 in. (208 cm) (in TURF mode)
Engine ES550PLE
Displacement 549.7 cc
Bore x Stroke 96.6 x 75
Alternator Output 490w @ 1350 RPM/Peak 630w
Compression Ratio 9.6:1
Starting System Electric
Ignition System Electronic Fuel Injection
Idle RPM** 1750 +/- 50
Ignition Timing 13 +/- 3 BTDC @ 1350 RPM, Engine warm
Spark Plug / Gap NGK BKR6E / .035 in. (0.9 mm)
Lubrication System Wet Sump
Driving System Type Automatic PVT (Polaris Variable Transmission)
Front Suspension Dual A-Arm with 9" (22.9 cm) travel
Rear Suspension Progressive rate with 10" (25.4 cm) travel
