Panasonic DP-2000 - Manual (Page 145)

145
Docum
e
nt Mana
g
e
m
e
n
t
Syst
em Secti
o
n
Configuration Editor
Main Window
This utility allows you to edit the machine configuration through the Parallel Port connected between the
PC and the device.
Startup Windows, and select Panasonic ➝ Panasonic Document Management System ➝ MFP Utilities
➝ Configuration Editor from the Programs in the Start menu to display the configuration editor dialog
box.
Each setting category appears as a folder on the left frame and the setting item appears on the right frame.
If the device is turned "Off" or not connected, a
dialog box appears as below. You may select.
Retry : After turned "On" the power or
connected the device.
Work Off-Line: Edit the data from an existing
file.
Exit : Exit the program.
When there is more than 1 supported model series
installed, a "Browse for Folder" dialog box appears
as below.
Select the model series folder and click OK.
