Phone 1 & Phone 2 54
SmartLink 4020 Getting Started Guide 6 • Telephony
FAX without T.38 (Use G.711 fax)
When checked, T.38 is disabled and the SL4020 will not attempt T.38 session negotiation for fax transmissions
initiated by the originator of the fax. The fax transmissions will be transported using G.711 fax pass-through.
The selection of T.38 or G.711 fax pass-through for fax transmissions originated from the SL4020 will be
determined by the receiving fax device. T.38 is enabled by default.
To disable T.38, go to Telephony > CODECS and select FAX without T.38 (Use G.711 fax) (see figure 29 on
page 53).
Saving your work
When you are finished configuring CODEC settings, click the Save CODEC Configuration button (see
figure 29 on page 53) to save the changes.
Phone 1 & Phone 2
The Phone 1 and Phone 2 windows contains the following sections:
• User Information (see figure 30 )
• Supplementary Service Settings (see figure 31 on page 56)
• Dial Out Type (see figure 32 on page 57)
• Call Forward Settings (see figure 26 on page 51)
• Selective Call Forward Settings (see figure 27 on page 51)
• Incoming Call Block (see figure 28 on page 52)
• Distinctive Ring Settings (see figure 28 on page 52)
• HTTP Digest Setting (see figure 28 on page 52)
Note After configuring the sections, click the Save button (see figure 37 on
page 59) to save the new configuration.
