System Status 27
SmartLink 4020 Getting Started Guide 3 • Home
Application Version
The SmartLink firmware version number.
Config Date
The date of the configuration file that was downloaded from an auto-upgrade server.
Security
Indicates that the SmartLink web interface utility has been secured with a password. To configure a password,
see section
“Set Security Password” on page 64.
Application Code Version
Shows the application code version being used.
Downloader Code Version
Shows the downloader code version being used.
System Status
Shows VoIP statistics for the period of time since the SmartLink 4020 was last reloaded (either by powering the
unit off and then on again, or by selecting System > Reload).
SIP Messages Sent
Total number of VoIP SIP messages sent (including retransmissions).
SIP Messages Received
Total number of VoIP SIP messages received (including retransmissions).
SIP Bytes Sent
Total number of bytes of VoIP SIP messages sent (including retransmissions).
SIP Bytes Received
Total number of bytes of VoIP SIP messages received (including retransmissions).
RTP Packets Sent
Total number of VoIP RTP packets sent (including redundant packets).
RTP Packets Received
Total number of VoIP RTP packets received (including redundant packets).
RTP Bytes Sent
Total number of VoIP RTP bytes sent.
RTP Bytes Received
Total number of VoIP RTP bytes received.
