Polycom RMX 1500 Hardware Guide

1-21

RMX 1500 Rear Panel LEDs

RTM IP 1500 LEDs

The following LEDs appear on the RTM IP 1500:

Table 1-10

RTM IP 1500 LEDs

Component

LED
Name

LED Color

Indication

LAN LEDs (1-2)

LNK

Green

ON with an active network
connection, flickers with Packet
activity.

1 Gb

Amber

ON with a 1Gb online
connection, flickers with Packet
activity.

MNG LED

LNK

Green

ON with an active network
connection, flickers with Packet
activity.

1 Gb

Amber

ON with a 1Gb online
connection, flickers with Packet
activity.

MNG B LED

LNK

Green

ON with an active network
connection, flickers with Packet
activity.

1 Gb

Amber

ON with a 1Gb online
connection, flickers with Packet
activity.

Shelf LED

LNK

Green

ON with an active network
connection, flickers with Packet
activity.

100

Amber

ON when the active network is
10/100Mb, flickers with Packet
activity.
