About this guide
This guide describes installing and operating the Patton Electronics Model 3231 Industrial Ethernet Extender
with LCD interface.
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
on page 13 provides information about 3231 features and capabilities.
•
on page 18 contains an overview describing 3231 operation and configuration.
•
on page 28 provides describes how to configure and monitor G.SHDSL.
•
on page 34 provides describes how to configure settings using the web interface.
•
on page 39 describes how to save the configuration, reset the 3231 to the factory default condi-
tion, and upgrade the system software.
•
on page 43 contains information on contacting Patton technical support for assistance.
•
on page 46 contains compliance information for the 3231.
•
on page 49 contains specifications for the 3231.
•
on page 53 describes the DSL port pin-out.
•
on page 55 describes the Ethernet port pin-out.
•
on page 57 describes the Console port pin-out.
For best results, read the contents of this guide before you install the 3231.
