Rear Panel 17
Model 3231 User Manual 1 • General information
Rear Panel
Figure 3. Model 3231 rear panel
Application
The Model 3231 is used as a network extender using a PPPoH bridge over DSL. PPPoH is an Ethernet exten-
sion because the same logical LAN exists at both ends of the modems and only bridging is required. PPPoH is
network extension in the more general sense since a different logical network is on each end of the modems.
Power
Model 3231
Console
RS-232 port
Ethernet
Reset
Line
Power
Ethernet
RJ-45 port
Reset
button
G.SHDSL
RJ-11 port
Ground
5V, 1A Console
Ethernet
Reset
Line
Power
5V , 1A
Console
