Planet Technology Internet Telephony PBX System IPX-300 Series User Manual

Page 61

Figure D-4. Add extension setting of IP PBX

STEP 4:

Please log in VIP-154T and browser to “SIP setting

Æ Domain Service” configuration menu.

Insert the account/password information then save and reboot machine. The sample configuration

screen is shown below:

The IP address
of IP PBX

Data match with Figure D-3.
IP PBX’s extension settings

Figure D-5. Web page of VIP-154T

STEP 5:

Please take VIP-192 and setup the wireless network to connect with IP PBX (IPX-300W) by

keypad menu method. Then log in VIP-192 via web browser and browser to “SIP Settings”

configuration menu. Insert the Register and Outbound Proxy IP Address information.
