User Guide V
2
IU 4300T Converged Network Appliance
Appendix - 12
V2IU B
1.
Setup the Network settings.
(Configuration -- Neighboring Gatekeeper -- Neighbors -- Add)
a
LAN interface IP address = 192.168.1.1
b
LAN interface subnet = 255.255.255.0
c
WAN interface IP address = 64.10.10.10
d
WAN interface subnet = 255.255.255.0
e
Default Gateway = 64.10.10.1
2.
Setup the VoIP ALG – H323 settings
V2IU B is set to use a LAN side gatekeeper, which is 192.168.1.45.
a
Gatekeeper Mode = LAN / subscriber side gatekeeper
b
LAN / subscriber side Gatekeeper Address = 192.168.1.45
Gatekeeper B
3.
On the Path Navigator (GK B), setup two Neighboring Gatekeeper
profiles.
a
In the Add Neighbor Gatekeeper dialog box, add the IP address of the
LAN side V2IU B (192.168.1.1). Click OK.
a
In the Add Neighbor Gatekeeper dialog box, add the IP address of the
WAN side V2IU A (69.52.177.69). Click OK.
Note
The reason for setting up the Neighboring statement with the LAN side of the V2IU
B is to enable outbound dialing to standalone endpoints on the public network.
Note
The reason for setting up the Neighboring statement with the WAN side of the V2IU
A is to neighbor with the Path Navigator that is on the LAN side of V2IU A.
