About this guide
This guide describes the Model 3034/3038 hardware, installation and basic configuration.
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
on page 13 provides information about router features and capabilities
•
on page 19 contains an overview describing router operation and applications
•
on page 21 provides hardware installation procedures
•
on page 29 provides quick-start procedures for configuring the Model 3034/3038
•
on page 33 provides information for configuring the RS-232 ports via the CLI or the WMI
•
on page 40 contains information on contacting Patton technical support for assistance
•
on page 43 contains compliance information for the router
•
on page 46 contains specifications for the routers
•
on page 49 provides cable recommendations
•
on page 52 describes the router’s ports and pin-outs
•
on page 56 provides license information that describes acceptable usage of the software pro-
vided with the Model 3034/3038
For best results, read the contents of this guide
before
you install the router.
