3. Connecting the Model 3034/3038 to the network 32
Model 3034/3038 Getting Started Guide 4 • Initial configuration
Login
To access the Model 3034/3038, start the ssh application. Type the default IP address for the router into the
address field: 192.168.200.10. Accessing your Model 3034/3038 via an ssh session displays the login screen.
Type the factory default login: admin and password: .
login: admin
password:
Trinity#
Changing the IP address
You can set your IP address and network mask for the interface ETH 0 (LAN). Within this example a network
192.168.1.1/24 address is assumed. The IP address in this example is set to 192.168.1.1 (you should set this
the IP address given to you by your network provider).
Trinity# configure
Trinity[config]# interface ethernet eth0
Trinity[eth-eth0]# ip address 192.168.1.1 netmask 255.255.255.0
Trinity[eth-eth0]# no ip address 192.168.200.10
Note If you logged into the 3034/3038 with the IP address 192.168.200.10, you
will need to reset your PC IP address to an address in the same network such
as 192.168.1.5 and log back into the 3034/3038. Connectivity via the ssh
session will be lost once the 192.168.200.10 address is removed.
Saving the IP address
To save the unit’s IP address, login to the unit using admin, then use the following set of commands:.
Trinity# [eth-eth0]# end
Trinity# copy running-config startup-config
Trinity#
3. Connecting the Model 3034/3038 to the network
In general, the Model 3034/3038 will connect to the network via the LAN (ETH 0) port. This enables the
Model 3034/3038 to offer routing services to the PC hosts on LAN (ETH 1) port. The Model 3034/3038
Series is equipped with Auto-MDX Ethernet ports, so you can use straight-through or crossover cables for host
or hub/switch connections.
You can check the connection with the ping command from the Model 3034/3038 to another host on the net-
work:
Trinity#ping . If the WAN address is not set to DHCP, to ping a device
outside your local LAN you must first configure the default gateway.
Note For more detailed configuration instructions, see the Trinity Administrator’s
Reference Guide located on the CD that shipped with your unit or online at
www.patton.com.
The interconnecting cables shall be acceptable for external use
and shall be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceability.
CAUTION
