Rear and Front Panels
16
Model 3034/3038 Getting Started Guide
1 • General information
Rear and Front Panels
Model 3034/3038 rear panel
The Model 3034/3038 rear panel ports are described in
Note
The Model 3038 rear panels are shown below. The Model 3034 is
similar, except that 3034 models only have four RS-232 ports.
Figure 2. 3038 rear panels
3038/ D Models - X.21
RS-232 ports
Ethernet ports
X.21
interface
Power
connector
Reset
button
3038/ C Models - V.35
Ethernet ports
V.35
interface
RS-232 ports
Power
connector
Reset
button
Ethernet ports
Power
connector
Reset
button
3038/ K Models - T1/E1
Ethernet ports
T1/E1
connectors
RS-232 ports
Power
connector
Reset
button
