Rear and Front Panels 17
Model 3034/3038 Getting Started Guide 1 • General information
Table 3. Rear panel ports
Port Description
LAN ETH 0 Auto-MDX Ethernet port, RJ-45
LAN ETH 1 Auto-MDX Ethernet port, RJ-45
Composite Varies depending on model type:
• /C models: V.35 DTE interface on a DB-25 female connector
• /D models: X.21 interface on a DB-15 female connector
• /K models: T1/E1 interface on dual BNC connectors and an RJ-45 connector
RS-232 0-7 Four (Models 3034) to eight (Models 3038) serial asynchronous RS-232 ports with
an 8-pin RJ-45F interface
Console Used for service and maintenance, the Console port, an RS-232 RJ-45 connector,
connects the product to a serial terminal such as a PC or ASCII terminal (also called
a dumb terminal).
100-240 VAC 50-
60 Hz Electricity supply socket for main power cable.
