Server Management
Intel® SHG2 DP Server Board Technical Product Specification
Intel Order Number C11343-001
Revision 1.0
32
After the system is turned on, the power supply will assert the PWRGD+00 signal after all
voltage levels in the system have reached valid levels. The BMC receives PWRGD+00 and
after approximately 500 ms, asserts RST_P6_PWRGOOD, which indicates to the processors
and CSB5 that the power is stable. Upon RST_P6_PWRGOOD assertion, the CSB5 will toggle
PCI reset.
5.2.2 Hard
Reset
A hard reset can be initiated by resetting the system through the front panel switch. During the
reset, the Sahalee BMC de-asserts RST_P6_PWR_GOOD. After 500 ms, it is reasserted, and
the power-up reset sequence is completed.
The Sahalee BMC is not reset by a hard reset. It may be reset at power-up.
5.2.3 Soft
Reset
A soft reset causes the processors to begin execution in a known state without flushing caches
or internal buffers. Soft resets can either be generated by SIO(KBD_PINITN),
CSB5(RSB_PINITN), or by the CMIC-LE(CMIC_PINITN).
P CIRST
32b PCI Slots
PSON
PSU
CM IC -
LE
NIC
Hudson II/III
Front Panel
Power button
R eset button
S leep button
Front Panel
Connector
BASEBO ARD
M ANAG EM ENT
CO NTROLLER
(BM C)
debounce
logic
S
leep
Po
w
e
r
Re
s
e
t
PW RGD
CPURST
Processor
Processor
Video
SCSI
isolation
reset
gateing
BM C video gate
M isc
(EMP,
IPMB Isolation
logic, etc)
VRD
Pgood
logic
PLL rst
logic
CSB5
C IOB
PCIRST
PCIRST
Sec PCI Slots
Pri PCI Slots
Reset out
Pw r
Conn
GPIO
Figure 8. Basic Reset Flow
