Page 78
The non-numbered parts are not kept as standard service parts.
15.2. Replacement Parts List (Indoor Unit)
REF. NO.
PART NAME & DESCRIPTION
QTY.
CS-TE9DKE
CS-TE12DKE
REMARKS
D1
CHASSY COMPLETE
1
CWD50C1418
←
←
←
←
D2
INSTALLATION PLATE
1
CWH361074
←
←
←
←
D3
PIPE HOLDING PLATE
1
CWD911465
←
←
←
←
D4
FAN MOTOR
1
ARW41E8P30AC
←
←
←
←
0
D5
CROSS FLOW FAN COMPLETE
1
CWH02K1029
←
←
←
←
D5-1
SCREW - CROSS FLOW FAN
1
CWH4580304
←
←
←
←
D6
BEARING ASS’Y
1
CWH64K1005
←
←
←
←
D7
DISCHARGE GRILLE COMPLETE
1
CWE20C2423
←
←
←
←
D7-1
VERTICAL VANE
1
CWE24C1115
←
←
←
←
D7-2
HORIZONTAL VANE COMPLETE (R)
1
CWE24C1106
←
←
←
←
D7-3
HORIZONTAL VANE COMPLETE (L)
1
CWE24C1107
←
←
←
←
D7-4
FULCRUM
1
CWH621050
←
←
←
←
D7-5
CAP (DRAIN CAP)
1
CWH521091
←
←
←
←
D7-6
AIR SWING MOTOR
1
CWA981106
←
←
←
←
0
D8
DRAIN HOSE
1
CWH851107
←
←
←
←
E1
CONTROL BOARD CASING
1
CWH102280
←
←
←
←
E2
TERMINAL BOARD COMPLETE
1
CWA28C2233
←
←
←
←
0
E4
DISPLAY PCB HOLDER
1
CWD932475
←
←
←
←
E5
ELECTRONIC CONTROLLER - RECEIVER, INDICATOR
1
CWA743634
←
←
←
←
0
E7
POWER SUPPLY CORD
1
CWA20C2432
←
←
←
←
E8
ELECTRONIC CONTROLLER - MAIN
1
CWA73C1810
←
←
←
←
0
E9
CONTROL COVER (LOWER)
1
CWH131229
←
←
←
←
E10
CONTROL COVER (PLASTIC PLATE - UPPER)
1
CWH131232
←
←
←
←
E11
CONTROL COVER (STEEL PLATE - UPPER)
1
CWH131230
←
←
←
←
E12
GEAR (FRONT PANEL OPEN/CLOSE MOTOR)
1
CWH68C1022
←
←
←
←
E12-1
FRONT PANEL OPEN/CLODE MOTOR
1
CWA981126
←
←
←
←
E13
SENSOR HOLDER (PIPE TEMP)
1
CWH32137
←
←
←
←
E14
ELECTRONIC CONTROLLER - IONIZER
1
CWA73C1791
←
←
←
←
E15
ION GENERATOR
1
CWH94C0005
←
←
←
←
F1
FRONT GRILLE COMPLETE
1
CWE11C3206XA
←
←
←
←
F1-1
FRONT PANEL (INTALE GRILLE)
1
CWE22C1184XA
←
←
←
←
F1-2
DOOR (INTERCONNECT CABLE)
1
CWE141087A
←
←
←
←
F1-3
INDICATOR
1
CWE312539
←
←
←
←
F2
CAP
2
CWH521121
←
←
←
←
F3
AIR FILTER
2
CWD001149
←
←
←
←
R1
EVAPORATOR COMPLETE (WITH PIPE)
1
CWB30C1608X
CWB30C1706X
R1-1C
FLARE NUT (1/4”)
1
CWT25086
←
←
←
←
R1-2
EVAPORATOR HOLDER
1
CWD61048
←
←
←
←
R3
FLARE NUT (3/8”)
1
CWT25087
R3
FLARE NUT (1/2”)
1
CWT25096
Z1
REMOTE CONTROL COMPLETE
1
CWA75C2686X
←
←
←
←
Z2-1
OPERATION INSTRUCTION
1
CWF564718
←
←
←
←
Z2-2
OPERATION INSTRUCTION
1
CWF564719
←
←
←
←
Z2-3
INSTALLATION INSTRUCTION
1
CWF612743
←
←
←
←
(Note)
•
•
•
•
All parts are supplied from ACD, Japan.
•
•
•
•
“O” marked parts are recommended to be kept in stock.
78
CS-TE9DKE CU-TE9DKE / CS-TE12DKE CU-TE12DKE
