CPD10WALLARM
Installation Instructions Visit Premier Mounts website at http://www.mounts.com Page 3
Parts List
Installation Tools
The following tools may be required, dependent upon your particular installation. These tools are not provided by
Premier Mounts, but you can purchase them at your local hardware store.
Your Premier Mounts product is shipped with all proper installation hardware and components. Make sure that none
of these parts are missing and/or damaged before beginning installation. If there are parts missing and/or damaged,
please stop the installation and contact Premier Mounts (800) 368-9700.
Pencil
Phillips Tip
Screwdriver Tape Measure Hand Held Drill Protective Eyewear
CPD10WALLARM Media Box Hardware
¼˝ Wood Drill Bit Electronic Stud Finder
Level
½˝ Socket and
Socket Wrench
2
1
Wall Plate
(Qty 1)
Arm Assembly
(Qty 1)
Adjustable Mounting Assembly
Pre-Assembled (Qty 1)
End Cover
(Qty 1)
Inner Slide Plate
(Qty 1)
Security Wrenches
M6 x 12mm Security
Head Screws (Qty 2)
M6 Set Screws
Security
(Qty 1)
Non-Security
(Qty 1)
M3
M5
¼˝ Nylon Spacer
(Qty 4)
M6 Flat Washer
(Qty 2)
External Slide Plate
(Qty 1)
M5 x 8mm Security Head
Screws (Qty 7)
M6 x 25mm Security
Head Screws (Qty 2) 5
16
˝ x 3˝ Lag Bolts (Qty 4)
Square Washers
(Qty 4)
Extension Arm
(Qty 1)
Wall Plate Covers
(Qty 1)
Projector
Bracket (Qty 1)
M4 x 10mm Combo Screw
(Qty 4)
M4 x 10mm Lock-It™
Security Screw
(Qty 4)
Projector Bracket Hardware Hardware
