68
The procedures described below let you set the parame-
ters for the Disk Recorder to communicate with external
devices.
1. Move the cursor to COMMUNICATION SETUP in the
WJ-HD500 SETUP menu by pressing the C or D but-
ton, then press the SET button.
The COMMUNICATION SETUP menu shown below
appears on the monitor screen.
2. Select an item or item parameter in the menu by press-
ing the D or C button.
3. To return to the previous WJ-HD500 SETUP menu,
press the SETUP/ESC button.
■ PS
• Data Setup
These items let you set the parameters for communication
between the System Controllers and the Disk Recorders
when the system is controlled with the PS
• Data mode
(Panasonic Security Data).
1. Move the cursor to PS • Data SETUP in the COMMUNI-
CATION SETUP menu by pressing the C or D button,
then press the SET button.
The PS
• Data SETUP menu shown below appears on
the monitor screen.
2. Select an item or item parameter in the menu by press-
ing the D or C button.
3. To return to the previous setup menu, press the
SETUP/ESC button.
● Unit Address Setting
This item lets you set the unit address of the Disk Recorder
in the system for RS-485 communication.
1. Move the cursor to the UNIT ADDRESS parameter by
pressing the D or C button.
2. Select the unit address number to be used for RS-485
communication by pressing the + or - button.
Select a parameter value between 001 and 099.
The factory default setting is 001.
● Baud Rate
This item lets you set the transmission speed for RS-485
communication.
1. Move the cursor to the BAUD RATE parameter by
pressing the D or C button.
2. Select the desired transmission speed shown below by
pressing the + or - button.
The factory default setting is 9 600 bps.
● Data Bit
This item lets you set the number of data bits for RS-485
communication.
The factory default setting is 8 bits and fixed.
8 COMMUNICATION SETUP
PS•Data SETUP
RS232C SETUP
NETWORK SETUP
DHCP OFF
IP ADDRESS 192.168.000.010
NETMASK 255.255.255.000
GATEWAY 192.168.000.001
8-1 PS•Data SETUP
UNIT ADDRESS 001
BAUD RATE 9600
DATA BIT 8
PARITY CHECK NONE
STOP BIT 1
WAIT TIME OFF
ALARM DATA 1S
CAMERA NUMBER SETUP
↔ 2 400 ↔ 4 800 ↔ 9 600 ↔19 200 ↔ 38 400 ↔
COMMUNICATION SETUP
