2 Lift offset too many
counts greater than
nominal
3 Lift offset less than neg-
ative physical bound-
ary count
4 Lift offset greater than
positive physical
boundary count
C3 1 Pivot offset fail-
ure Pivot offset too many
counts less than nomi-
nal Pivot flags,
pivot circuit
board, pivot
cable, pivot
gear mesh Verify pivot flags OK, pivot
sensors working, pivot gear
mesh is not too tight
2 Pivot offset too many
counts greater than
nominal
3 Pivot offset less than
negative physical
boundary count
4 Pivot offset greater than
positive physical
boundary count
C4 1 Offset target fail-
ure Target could not be
found Offset target,
offset sensor
on MTE Verify offset targets not dam-
aged, Offset sensor is work-
ing or replace MTE
2 Target horizontal posi-
tion found crudely, but
not with fine resolution
3 Target vertical position
found crudely, but not
with fine resolution
4 Reference target not
found
C5 1 Offset ref failure Reference could not be
found Offset refer-
ence sensor Verify reference sensor work-
ing, Replace MTE or detec-
tor in chassis
2 Reference vertical posi-
tion found crudely, but
not with fine resolution
Error
Code
(hex)
Sub-
code
Error
Description
Subcode
Description
Compo-
nent
Corrective Action
