Appendix D Plasmon D875 - D2175 User Manual
Page 70 Document Revision E
16 1 Can time out -
mag board CAN time out sending
command to flipper Magazine
interface cir-
cuit board,
CAN cables Replace magazine interface
circuit board or CAN G103
cables
2 CAN time out reading
flipper EEPROM
3 CAN time out writing
flipper EEPROM
4 CAN time out checking
mag interface circuit
board
5 CAN time out read mag
sensors
6 CAN time out reading
mag interface circuit
board temp
7 CAN time out turning
on mag LED
8 CAN time out turning
off mag LED
9 CAN time out blinking
mag LED
10 CAN time out firing mag
door solenoid
11 CAN time out start ver-
ify temp
12 CAN time out reset
mag door state
17 1 Main board
SCSI termpower No term pwr at MC
SCSI adapter circuit
board
18 1 Power supply
voltage 5V out of range during
check main circuit
board cable check Bad power
supply Replace power supply
2 12V out of range during
check main circuit
board cable check
Error
Code
(hex)
Sub-
code
Error
Description
Subcode
Description
Compo-
nent
Corrective Action
